先看一下ui效果图，当前是vue3，注意一点抖音的和微信有点不同。
分析一下当前海报中的元素。1.首先有一个水印 2.背景图 3.文字居中 4.文字标签带边框 5.图片列表 6.二维码生成 7.弹窗保存8.下载网络图片资源
1.水印生成
// 绘制水印
export function drawWatermark(ctx, width, height, text = 'SAMPLE', color = '#000', alpha = 0.05) {
ctx.save();
// 设置透明度
ctx.globalAlpha = alpha;
// 设置字体（建议粗体更清晰）
ctx.font = ' 12px Arial';
ctx.fillStyle = color;
ctx.textAlign = 'center';
ctx.textBaseline = 'middle';
// 可选：旋转水印（45度斜向）
const angle = (-25 * Math.PI) / 180; // 转为弧度（-25度）
ctx.translate(width / 2, height / 2);
ctx.rotate(angle);
// 计算水印间距（根据文字长度动态调整）
const textWidth = ctx.measureText(text).width;
const spacingX = textWidth * 1.5; // 水平间距
const spacingY = 100; // 垂直间距
// 铺满整个区域
for (let x = -width; x < width; x += spacingX) {
for (let y = -height; y < height; y += spacingY) {
ctx.fillText(text, x, y);
}
}
ctx.restore(); // 恢复状态（重置透明度、旋转等）
}
传入canvas 宽，高，水印文本 宽高指的是水印的区域
drawWatermark(ctx, widths.value, heights.value, assess.value.watermark);
2.背景图
这里的背景图有两种情况一种是小程序的静态资源，一种是网络图片（从后请求的图片路径）。本地的小程序canvas可以直接使用，网络图片需要先下载成为临时路径后再使用。
// 此方法是图片预加载和路径转换
async function preloadMediaImages(list) {
if (!Array.isArray(list)) {
console.warn('[preloadMediaImages] 输入不是数组:', list);
return [];
}
const urls = list
.filter((item) => item?.path && (item.type === 'image' || item.type === 'video'))
.map((item) => {
if (item.type === 'image') return item.path;
const sep = item.path.includes('?') ? '&' : '?';
return `${item.path}${sep}x-oss-process=video/snapshot,t_0,f_jpg,w_120,h_120,m_fast`;
});
if (urls.length === 0) return [];
return await Promise.all(
urls.map(
(url) =>
new Promise((resolve) => {
uni.getImageInfo({
src: url,
success: (res) => resolve(res.path),
fail: () => resolve('/static/placeholder.png')
});
})
)
);
}
此方法可以传出视频路径和图片路径，阿里云通过路径拿到视频第一帧作为图片展示。
preloadMediaImages([
{ type: 'image', path: proxy.$IMGURL + 'v17.png' },
{ type: 'image', path: proxy.$IMGURL + 'v17a.png' }
]).then((res) => {
uulist.value = res;
});
/**
* 在 Canvas 上绘制带圆角的图片（常用于头像、二维码等）
* 通过 clip 裁剪出圆角矩形区域，再绘制图片
* @param {Object} ctx - canvas 上下文对象（由 uni.createCanvasContext 创建）
* @param {string} img - 图片本地路径（必须是 getImageInfo 返回的 path）
* @param {number} x - 图片左上角 X 坐标（单位：px，已按比例缩放）
* @param {number} y - 图片左上角 Y 坐标
* @param {number} width - 图片绘制宽度
* @param {number} height - 图片绘制高度
* @param {number} radius - 圆角半径（建议 ≤ min(width, height)/2）
* @param {boolean} shadow - 是否添加红色阴影（用于特殊效果，如印章）
*/
export function drawRoundedImage(ctx, img, x, y, width, height, radius, shadow = false) {
ctx.save()
ctx.beginPath()
// 左上角
ctx.moveTo(x + radius, y)
// 右上角
ctx.lineTo(x + width - radius, y)
ctx.arc(x + width - radius, y + radius, radius, Math.PI * 1.5, Math.PI * 2)
// 右下角
ctx.lineTo(x + width, y + height - radius)
ctx.arc(x + width - radius, y + height - radius, radius, 0, Math.PI * 0.5)
// 左下角
ctx.lineTo(x + radius, y + height)
ctx.arc(x + radius, y + height - radius, radius, Math.PI * 0.5, Math.PI)
// 左上角闭合
ctx.lineTo(x, y + radius)
ctx.arc(x + radius, y + radius, radius, Math.PI, Math.PI * 1.5)
ctx.closePath()
if (shadow) {
ctx.shadowBlur = 20
ctx.shadowColor = 'red'
}
ctx.clip() // 裁剪出圆角区域
ctx.drawImage(img, x, y, width, height)
ctx.restore()
}
// 背景图 uulist.value这个是通过上面方法拿到的临时路径
drawRoundedImage(ctx, assess.value.type == 1 ? uulist.value[1] : uulist.value[0], 0, 0, widths.value, heights.value, 10);
3.文字居中
居中的文字对应我这里的价格
/**
* 绘制单行文本（支持自动省略）
* @param {Object} ctx - canvas 上下文
* @param {string} font - 字体样式，如 '18px Arial'
* @param {string} align - 对齐方式 ('left' | 'center' | 'right')
* @param {string} fillStyle - 文字颜色
* @param {string} text - 要绘制的文本
* @param {number} x - 绘制 X 坐标
* @param {number} y - 绘制 Y 坐标（基线位置）
* @param {number|null} maxWidth - 最大宽度，超过则省略（可选）
*/
export function drawText(ctx, font, align, fillStyle, text, x, y, maxWidth = null) {
ctx.font = font;
ctx.textAlign = align; // ← 直接使用原生对齐！
ctx.textBaseline = 'alphabetic';
ctx.fillStyle = fillStyle;
let finalText = text;
if (maxWidth != null) {
finalText = truncateText(ctx, text, maxWidth);
}
ctx.fillText(finalText, x, y); // x 就是 align 的参考点
}
drawText(ctx, 'bold 48px Arial', 'center', '#242424', assess.value.assessPrice, widths.value / 2, 300 / ratio.value);
4.文字标签带边框
累计估价量，准确率，从事估价行业等内容居中带边距带边框有圆角。
/**
* 绘制多个水平排列的标签（自动测宽 + 间距）
* @param {Object} ctx - canvas 上下文
* @param {Array<{text: string}>} items - 标签数据
* @param {number} startX - 起始 X（左上角）
* @param {number} startY - 起始 Y（左上角）
* @param {number} spacing - 标签之间的水平间距（px，已缩放）
* @param {Object} style - 样式配置
*/
function drawMultipleLabels(ctx, items, startX, startY, spacing, style = {}) {
const { font = '10px Arial', textColor = '#979797', borderColor = '#d1d1d6', fillColor = '#ffffff', paddingX = 4, paddingY = 2 } = style;
let currentX = startX;
items.forEach((item) => {
// 1. 测量当前标签宽度
ctx.font = font;
const textWidth = ctx.measureText(item.text).width;
const labelWidth = textWidth + paddingX * 2;
// 2. 绘制当前标签
drawTextWithBorderBox(ctx, item.text, currentX, startY, font, textColor, borderColor, fillColor, paddingX, paddingY);
// 3. 更新 X 坐标（加上当前标签宽度 + 间距）
currentX += labelWidth + spacing;
});
}
这是使用方法
const startX = 50 / ratio.value; // 第一个标签的起始x位置
const startY = 410 / ratio.value; // 第一个标签的起始y位置
const spacingX = 10; // 标签之间的水平间距
const texts = [{ text: `累计估价量${user.value.assessCount}+` }, { text: `准确率${user.value.assessRatio}%+` }, { text: `从事估价行业${user.value.assessYear}年` }];
drawMultipleLabels(ctx, texts, startX, startY, spacingX);
5.图片列表
我这里的展示的内容有图片也有视频，所以采用上面的方法把mp4拿到的第一帧作为图片展示出来。
preloadMediaImages使用此方法。这个就简单了，for循环图片数组就可以了，注意是已经把网络路径下载到本地之后的图片数组。
localPaths.value.forEach((path, i) => {
if (path) drawRoundedImage(ctx, path, (50 + i * 125) / ratio.value, 670 / ratio.value, 120 / ratio.value, 120 / ratio.value, 4);
});
6.二维码生成
生成二维码使用uqrcode，同时也需要用到canvas标签。最好在页面进来后就加载二维码，这样等点击弹窗的时候二维码已经生成完毕了。
先引入uqrcode.js，uqrcode.js文件有点大放到最后。
//页面标签
<canvas v-if="isshow" canvas-id="qrcode" style="width: 100px; height: 100px"></canvas>
import uQRCode from '@/utils/uqrcode.js';
//最好在页面刚进来就开始加载二维码
uQRCode.make({
canvasId: 'qrcode',
componentInstance: getCurrentInstance(),
text: option.code,
width: 100,
height: 100,
size: 100,
success: (res) => {
uni.canvasToTempFilePath({
canvasId: 'qrcode',
width: 100,
height: 100,
destWidth: 100,
destHeight: 100,
quality: 1,
fileType: 'jpg',
success: (fileRes) => {
imgEWM.value = fileRes.tempFilePath; // ✅ 这才是真机能用的路径
isshow.value = false;
}
});
},
fail: (err) => {
console.error('二维码绘制失败', err);
}
});
7.弹窗展示图片，点击保存
这个很简单，最后生成完毕把页面的弹窗展示出来就好了。
// 渲染并导出
ctx.draw(false, () => {
setTimeout(() => {
uni.canvasToTempFilePath({
canvasId: 'posterCanvas',
destWidth: widths.value * 2,
destHeight: heights.value * 2,
quality: 1,
fileType: 'jpg',
success: (res) => {
imgHB.value = res.tempFilePath;
uni.hideLoading();
canvasPop.value.open();
isshowHb.value = false;
},
fail: (err) => {
uni.hideLoading();
uni.showToast({ title: '绘制失败', icon: 'none' });
console.error('canvasToTempFilePath fail:', err);
}
});
}, 100);
});
<uni-popup ref="canvasPop" type="center">
<view class="canvasCss">
<uni-icons @click="canvasPop.close()" class="icons" type="close" color="#fff" size="24"></uni-icons>
<image show-menu-by-longpress :src="imgHB" mode="" style="border-radius: 10rpx"></image>
<view class="btns" @click="saveImage">
<view class="b flex_jc_cent">
<image src="/static/valuation/xz.png" mode=""></image>
</view>
保存
</view>
</view>
</uni-popup>
保存图片方法
function saveImage() {
uni.saveImageToPhotosAlbum({
filePath: imgHB.value,
success: function () {
uni.showToast({
icon: 'none',
position: 'bottom',
title: '已保存到系统相册'
});
},
fail: function (error) {}
});
}
8.当前页面代码
以上就是所有用到的方法，接下来把页面全部代码给出来仅供参考。不要直接粘贴复制，先好好看一下。
<template>
<view>
<view class="content">
<image class="bcg" :style="assess.type == 1 ? { filter: 'grayscale(100%)' } : {}" :src="$IMGURL + 'v17.png'" mode=""></image>
<image class="ads" src="/static/valuation/v20.png" mode=""></image>
<view class="content_ads">
<image class="topimg" src="/static/valuation/login1.png" mode=""></image>
<view class="t1">梦幻商人估价-{{ assess.type == 1 ? '普通报告' : '专家报告' }}</view>
<image class="img1" :style="assess.type == 1 ? { filter: 'grayscale(100%)' } : {}" src="/static/valuation/v18.png" mode=""></image>
<view class="ms">
单位：元（可等比例换算游戏货币）
<view class="price">{{ assess.assessPrice }}</view>
</view>
<view class="hairline" style="margin: 26rpx auto"></view>
<view class="user">
<view class="title">资深鉴别师-{{ user.nickname }}</view>
<view class="flex">
<view class="its">累计估价量{{ user.assessCount }}+</view>
<view class="its">准确率{{ user.assessRatio }}%+</view>
<view class="its">从事估价行业{{ user.assessYear }}年</view>
</view>
</view>
<view class="hairline" style="margin: 26rpx auto 10rpx"></view>
<view class="ics flex_jc_sb">
<view class="l">报告编码</view>
<view class="r">{{ assess.assessCode }}</view>
</view>
<view class="ics flex_jc_sb">
<view class="l">报告有效期至</view>
<view class="r">{{ pageformatISODate(assess.expEndTime) }}</view>
</view>
<view class="hairline" style="margin: 26rpx auto 20rpx"></view>
<view class="tmList">
<view class="tit">用户估价信息</view>
<view class="sub">估价内容：{{ assess.assessContent }}</view>
<!-- 图片或者视频 -->
<view class="upload-area">
<!-- 图片区域 -->
<view class="preview-img" v-for="(url, idx) in image_video.slice(0, 5)" :key="'img-' + idx" @click="opens(idx)">
<image v-if="url.type == 'image'" class="uimg" :src="url.path" mode="aspectFill" />
<view v-else class="preview-video">
<image class="uimg" :src="url.path + '?x-oss-process=video/snapshot,t_0,f_jpg,w_120,h_120,m_fast'" mode="aspectFill" />
<view class="ivideo_ads flex_jc_cent">
<image class="as" src="/static/trad/video.png" mode=""></image>
</view>
</view>
<view class="adstext" v-if="idx == 4">查看更多</view>
</view>
<!-- 视频区域 -->
</view>
</view>
<view class="hairline" style="margin: 30rpx auto 20rpx"></view>
<view class="sm">
<view class="sm_tit" style="margin-bottom: 10rpx">声明：</view>
<view class="">
{{ explain }}
</view>
</view>
<view class="imgflex flex_jc_cent">
<view class="flex">
<image class="img" :style="assess.type == 1 ? { filter: 'grayscale(100%)' } : {}" src="/static/valuation/v19.png" mode=""></image>
专业估价师根据用户提供的信息所评估
<image class="img i2" :style="assess.type == 1 ? { filter: 'grayscale(100%)' } : {}" src="/static/valuation/v19.png" mode=""></image>
</view>
</view>
<view
class="watermark-item"
v-for="(item, index) in watermarkItems"
:key="index"
:style="{
top: `${item.top}px`,
left: `${item.left}px`,
transform: `rotate(${-25}deg)`,
fontSize: `14px`,
color: '#000',
opacity: 0.05,
lineHeight: `20rpx`
}"
>
<view class="">{{ assess.watermark }}</view>
</view>
</view>
</view>
<view class="" style="height: 220rpx"></view>
<view class="footer-con flex_jc_sb" v-if="imgEWM">
<view class="l_btn flex_jc_sb">
<view class="x" style="margin-right: 68rpx; margin-left: 20rpx" @click="drawPageImg">
<image src="/static/valuation/xz.png" mode=""></image>
下载
</view>
<view class="x">
<image src="/static/valuation/fx.png" mode=""></image>
分享
<button class="zf_btns" open-type="share">分享</button>
</view>
</view>
<view class="f-btn" @click="$copyToClipboard(assess.assessCode)">复制报告编码</view>
</view>
<canvas v-if="isshow" canvas-id="qrcode" style="width: 100px; height: 100px"></canvas>
<canvas v-if="isshowHb" canvas-id="posterCanvas" :style="{ width: canvasWidth, height: canvasHeight }" style="margin: 20rpx auto"></canvas>
<uni-popup ref="popup" type="center">
<view class="preview-container" @click="popup.close()">
<swiper
:indicator-dots="false"
:autoplay="false"
:interval="3000"
:duration="500"
@change="onSwiperChange"
:current="currentIndex"
style="width: 100%; height: 100%"
>
<swiper-item v-for="(item, index) in image_video" :key="index" class="flex_jc_cent">
<view class="media-item">
<image show-menu-by-longpress v-if="item.type == 'image'" class="media-img" :src="item.path" mode="aspectFill" />
<video
@click.stop=""
v-else
class="media-video"
:src="item.path"
:controls="true"
:show-fullscreen-btn="true"
:show-play-btn="true"
:enable-progress-gesture="true"
controlslist="nodownload"
playsinline
/>
</view>
</swiper-item>
</swiper>
<view class="page-indicator">{{ currentIndex + 1 }}/{{ image_video.length }}</view>
</view>
</uni-popup>
<uni-popup ref="canvasPop" type="center">
<view class="canvasCss">
<uni-icons @click="canvasPop.close()" class="icons" type="close" color="#fff" size="24"></uni-icons>
<image show-menu-by-longpress :src="imgHB" mode="" style="border-radius: 10rpx"></image>
<view class="btns" @click="saveImage">
<view class="b flex_jc_cent">
<image src="/static/valuation/xz.png" mode=""></image>
</view>
保存
</view>
</view>
</uni-popup>
</view>
</template>
<!-- 向您分享了一份官方估价报告 -->
<script setup>
import { ref, reactive, getCurrentInstance } from 'vue';
import { onLoad, onShow, onReachBottom, onPageScroll, onShareAppMessage } from '@dcloudio/uni-app';
import { assessCode } from '@/api/valuation.js';
import { drawRoundedImage, drawTextWithBorderBox, drawRoundedRect, drawText, drawLine, drawWatermark, drawWrappedText } from '@/utils/canvasUtils.js';
import uQRCode from '@/utils/uqrcode.js';
const { proxy } = getCurrentInstance();
const image_video = ref([]);
const explain = ref('');
const user = ref({});
const assess = ref({});
const pageformatISODate = (value) => {
const date = new Date(value);
const year = String(date.getFullYear()).padStart(4, '0');
const month = String(date.getMonth() + 1).padStart(2, '0'); // 月份从0开始
const day = String(date.getDate()).padStart(2, '0');
const hours = String(date.getHours()).padStart(2, '0');
const minutes = String(date.getMinutes()).padStart(2, '0');
const seconds = String(date.getSeconds()).padStart(2, '0');
return `${year}-${month}-${day}`;
};
const imgHB = ref('');
const isshowHb = ref(false);
const imgEWM = ref('');
const isshow = ref(true);
const shareCode = ref('');
onLoad(async (option) => {
shareCode.value = option.code;
preloadMediaImages([
{ type: 'image', path: proxy.$IMGURL + 'v17.png' },
{ type: 'image', path: proxy.$IMGURL + 'v17a.png' }
]).then((res) => {
uulist.value = res;
});
uQRCode.make({
canvasId: 'qrcode',
componentInstance: getCurrentInstance(),
text: option.code,
width: 100,
height: 100,
size: 100,
success: (res) => {
uni.canvasToTempFilePath({
canvasId: 'qrcode',
width: 100,
height: 100,
destWidth: 100,
destHeight: 100,
quality: 1,
fileType: 'jpg',
success: (fileRes) => {
imgEWM.value = fileRes.tempFilePath; // ✅ 这才是真机能用的路径
isshow.value = false;
}
});
},
fail: (err) => {
console.error('二维码绘制失败', err);
}
});
// 1. 获取报告数据
const res = await assessCode(option.code);
if (res.code !== 200) return;
image_video.value = res.data.image_video || [];
explain.value = res.data.explain;
user.value = res.data.user;
assess.value = res.data.assess;
// 2. 初始化 Canvas 尺寸（必须先完成）
initCanvasSize();
// 等待尺寸初始化完成（轮询直到 widths 变化）
await new Promise((resolve) => {
const check = () => {
if (widths.value !== 355) {
resolve();
} else {
setTimeout(check, 50);
}
};
check();
});
try {
const allPaths = await preloadMediaImages(image_video.value);
const validPaths = Array.isArray(allPaths) ? allPaths : [];
localPaths.value = validPaths.slice(0, 5);
} catch (err) {
localPaths.value = [];
}
// 4. 第二步：生成二维码（必须等 canvas 尺寸 ready + 页面存在 qrcode canvas）
});
const watermarkItems = ref([]);
function initWatermarkPositions() {
const items = [];
// 计算需要多少行和列水印
const columns = Math.ceil(710 / 140) + 1;
const rows = Math.ceil(1300 / 140) + 1;
// 生成水印位置
for (let i = 0; i < columns; i++) {
for (let j = 0; j < rows; j++) {
items.push({
left: i * 140 - 140 / 2,
top: j * 140 - 140 / 2
});
}
}
watermarkItems.value = items;
}
const currentIndex = ref(0);
// 滑动切换时更新索引
const onSwiperChange = (e) => {
currentIndex.value = e.detail.current;
};
const popup = ref(null);
const opens = (idx) => {
currentIndex.value = idx;
popup.value.open(idx);
};
const localPaths = ref([]);
const canvasWidth = ref('355px');
const canvasHeight = ref('650px');
const widths = ref(355);
const heights = ref(650);
const ratio = ref(2);
function initCanvasSize() {
uni.getSystemInfo({
success: (res) => {
const deviceWidth = res.screenWidth; // 设备真实宽度（如 iPhone 390, 小米 412 等）
const deviceRatio = 710 / deviceWidth; // 比例：750 / 设备宽
// 计算实际画布尺寸（按比例缩放）
const actualWidth = deviceWidth;
const actualHeight = (1300 / 710) * actualWidth;
// 更新响应式数据
widths.value = actualWidth;
heights.value = actualHeight;
ratio.value = deviceRatio; // 用于后续坐标换算：设计稿坐标 / ratio = 实际坐标
canvasWidth.value = actualWidth + 'px';
canvasHeight.value = actualHeight + 'px';
initWatermarkPositions();
},
fail: (err) => {
console.error('获取系统信息失败:', err);
}
});
}
/**
* 绘制多个水平排列的标签（自动测宽 + 间距）
* @param {Object} ctx - canvas 上下文
* @param {Array<{text: string}>} items - 标签数据
* @param {number} startX - 起始 X（左上角）
* @param {number} startY - 起始 Y（左上角）
* @param {number} spacing - 标签之间的水平间距（px，已缩放）
* @param {Object} style - 样式配置
*/
function drawMultipleLabels(ctx, items, startX, startY, spacing, style = {}) {
const { font = '10px Arial', textColor = '#979797', borderColor = '#d1d1d6', fillColor = '#ffffff', paddingX = 4, paddingY = 2 } = style;
let currentX = startX;
items.forEach((item) => {
// 1. 测量当前标签宽度
ctx.font = font;
const textWidth = ctx.measureText(item.text).width;
const labelWidth = textWidth + paddingX * 2;
// 2. 绘制当前标签
drawTextWithBorderBox(ctx, item.text, currentX, startY, font, textColor, borderColor, fillColor, paddingX, paddingY);
// 3. 更新 X 坐标（加上当前标签宽度 + 间距）
currentX += labelWidth + spacing;
});
}
// 此方法是图片预加载和路径转换
async function preloadMediaImages(list) {
if (!Array.isArray(list)) {
console.warn('[preloadMediaImages] 输入不是数组:', list);
return [];
}
const urls = list
.filter((item) => item?.path && (item.type === 'image' || item.type === 'video'))
.map((item) => {
if (item.type === 'image') return item.path;
const sep = item.path.includes('?') ? '&' : '?';
return `${item.path}${sep}x-oss-process=video/snapshot,t_0,f_jpg,w_120,h_120,m_fast`;
});
if (urls.length === 0) return [];
return await Promise.all(
urls.map(
(url) =>
new Promise((resolve) => {
uni.getImageInfo({
src: url,
success: (res) => resolve(res.path),
fail: () => resolve('/static/placeholder.png')
});
})
)
);
}
const uulist = ref([]);
const canvasPop = ref(null);
function drawPageImg() {
uni.showLoading({
title: '生成中...'
});
if (imgHB.value) {
uni.hideLoading();
canvasPop.value.open();
return;
}
isshowHb.value = true;
const ctx = uni.createCanvasContext('posterCanvas', getCurrentInstance());
// 背景色
drawRoundedRect(ctx, 0, 0, widths.value, heights.value, 10, '#FFFFFF');
// 水印
drawWatermark(ctx, widths.value, heights.value, assess.value.watermark);
// 背景图
drawRoundedImage(ctx, assess.value.type == 1 ? uulist.value[1] : uulist.value[0], 0, 0, widths.value, heights.value, 10);
ctx.drawImage(assess.value.type == 1 ? '/static/valuation/v21a.png' : '/static/valuation/v21.png', 140 / ratio.value, 66 / ratio.value, 426 / ratio.value, 44 / ratio.value);
ctx.drawImage(assess.value.type == 1 ? '/static/valuation/v18a.png' : '/static/valuation/v18.png', 156 / ratio.value, 134 / ratio.value, 400 / ratio.value, 28 / ratio.value);
drawText(ctx, '12px Arial, "PingFang SC"', 'left', '#979797', '单位：元', 200 / ratio.value, 200 / ratio.value);
drawText(ctx, '10px Arial, "PingFang SC"', 'left', '#979797', '(可等比例换算游戏货币）', 300 / ratio.value, 200 / ratio.value);
drawText(ctx, 'bold 48px Arial', 'center', '#242424', assess.value.assessPrice, widths.value / 2, 300 / ratio.value);
// drawLine(ctx, 50 / ratio.value, 350 / ratio.value, widths.value - 25, 350 / ratio.value, '#000', 0.5);
drawLine(ctx, 50 / ratio.value, 340 / ratio.value, widths.value - 25, 340 / ratio.value, '#EEEEEE', 0.5);
ctx.drawImage('/static/valuation/v20.png', 516 / ratio.value, 220 / ratio.value, 152 / ratio.value, 152 / ratio.value);
drawText(ctx, '14px Arial, "PingFang SC"', 'left', '#000000', `资深估价师-${user.value.nickname}`, 50 / ratio.value, 390 / ratio.value);
const startX = 50 / ratio.value; // 第一个标签的起始x位置
const startY = 410 / ratio.value; // 第一个标签的起始y位置
const spacingX = 10; // 标签之间的水平间距
const texts = [{ text: `累计估价量${user.value.assessCount}+` }, { text: `准确率${user.value.assessRatio}%+` }, { text: `从事估价行业${user.value.assessYear}年` }];
drawMultipleLabels(ctx, texts, startX, startY, spacingX);
drawLine(ctx, 50 / ratio.value, 470 / ratio.value, widths.value - 25, 470 / ratio.value, '#EEEEEE', 0.5);
drawText(ctx, '13px Arial, "PingFang SC"', 'left', '#979797', '报告编码', 50 / ratio.value, 510 / ratio.value);
drawText(ctx, '13px Arial, "PingFang SC"', 'right', '#000000', assess.value.assessCode, 660 / ratio.value, 510 / ratio.value);
drawText(ctx, '13px Arial, "PingFang SC"', 'left', '#979797', '报告有效期至', 50 / ratio.value, 570 / ratio.value);
drawText(ctx, '13px Arial, "PingFang SC"', 'right', '#000000', pageformatISODate(assess.value.expEndTime), 660 / ratio.value, 570 / ratio.value);
drawText(ctx, '13px Arial, "PingFang SC"', 'left', '#979797', '估价内容：', 50 / ratio.value, 640 / ratio.value);
drawText(ctx, '13px Arial, "PingFang SC"', 'left', '#979797', assess.value.assessContent, 170 / ratio.value, 640 / ratio.value, 500 / ratio.value);
localPaths.value.forEach((path, i) => {
if (path) drawRoundedImage(ctx, path, (50 + i * 125) / ratio.value, 670 / ratio.value, 120 / ratio.value, 120 / ratio.value, 4);
});
drawLine(ctx, 50 / ratio.value, 815 / ratio.value, widths.value - 25, 815 / ratio.value, '#EEEEEE', 0.5);
drawText(ctx, '13px Arial, "PingFang SC"', 'left', '#979797', '声明：', 50 / ratio.value, 855 / ratio.value);
drawWrappedText(ctx, explain.value, 50 / ratio.value, 855 / ratio.value, widths.value - 50, 20, '13px Arial, "PingFang SC"', '#979797');
ctx.drawImage('/static/valuation/v22.png', 50 / ratio.value, 1140 / ratio.value, 166 / ratio.value, 40 / ratio.value);
drawText(ctx, '12px Arial, "PingFang SC"', 'left', '#979797', '梦幻商人精准估价，交易不踩坑', 50 / ratio.value, 1230 / ratio.value);
ctx.drawImage('/static/valuation/pa.png', 556 / ratio.value, 1140 / ratio.value, 100 / ratio.value, 100 / ratio.value);
// 渲染并导出
ctx.draw(false, () => {
setTimeout(() => {
uni.canvasToTempFilePath({
canvasId: 'posterCanvas',
destWidth: widths.value * 2,
destHeight: heights.value * 2,
quality: 1,
fileType: 'jpg',
success: (res) => {
imgHB.value = res.tempFilePath;
uni.hideLoading();
canvasPop.value.open();
isshowHb.value = false;
},
fail: (err) => {
uni.hideLoading();
uni.showToast({ title: '绘制失败', icon: 'none' });
console.error('canvasToTempFilePath fail:', err);
}
});
}, 100);
});
}
function saveImage() {
uni.saveImageToPhotosAlbum({
filePath: imgHB.value,
success: function () {
uni.showToast({
icon: 'none',
position: 'bottom',
title: '已保存到系统相册'
});
},
fail: function (error) {}
});
}
onShareAppMessage((e) => {
return {
title: '向您分享了一份官方估价报告',
path: `pages/valuation/valuationShare?code=${shareCode.value}`
};
});
</script>
<style lang="scss">
page {
background: #272424;
}
.content {
width: 710rpx;
height: 1300rpx;
background: #fff;
margin: 20rpx auto;
border-radius: 8rpx;
position: relative;
.bcg {
position: absolute;
top: 0%;
width: 710rpx;
height: 1300rpx;
border-radius: 8rpx;
}
.ads {
position: absolute;
top: 314rpx;
right: 56rpx;
width: 152rpx;
height: 152rpx;
}
.content_ads {
position: absolute;
top: 0%;
width: 710rpx;
height: 1300rpx;
border-radius: 8rpx;
z-index: 1;
padding: 0rpx 50rpx;
box-sizing: border-box;
overflow: hidden;
.watermark-item {
position: absolute;
white-space: nowrap;
/* 防止文本换行 */
user-select: none;
/* 禁止选中 */
z-index: 12;
}
.topimg {
width: 230rpx;
height: 60rpx;
display: block;
margin: 92rpx auto 6rpx;
}
.t1 {
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 24rpx;
color: #979797;
text-align: center;
}
.img1 {
width: 400rpx;
height: 28rpx;
display: block;
margin: 14rpx auto;
}
.ms {
text-align: center;
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 24rpx;
color: #979797;
margin-top: 10rpx;
.price {
font-family: 'DINB';
font-weight: bold;
font-size: 96rpx;
color: #000;
}
}
.user {
.title {
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 28rpx;
color: #000000;
margin-bottom: 14rpx;
}
.its {
height: 28rpx;
background: #ffffff;
border-radius: 4rpx;
border: 1px solid #d1d1d6;
padding: 0rpx 8rpx;
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 20rpx;
color: #979797;
line-height: 28rpx;
margin-right: 8rpx;
}
}
.ics {
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 26rpx;
margin-top: 20rpx;
.l {
color: #979797;
}
.r {
color: #000000;
}
}
}
.tmList {
.tit {
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 26rpx;
color: #000000;
}
.sub {
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 26rpx;
color: #979797;
margin-top: 8rpx;
}
.upload-area {
display: flex;
flex-wrap: wrap;
gap: 1px;
margin-top: 18rpx;
.preview-img,
.preview-video {
width: 120rpx;
height: 120rpx;
border-radius: 4rpx;
position: relative;
.uimg,
.uvideo {
width: 100%;
height: 100%;
border-radius: 4rpx;
}
.ivideo_ads {
width: 120rpx;
height: 120rpx;
border-radius: 4rpx;
position: absolute;
top: 0%;
.as {
width: 40rpx;
height: 40rpx;
}
}
}
.adstext {
width: 120rpx;
height: 36rpx;
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 20rpx;
color: #ffffff;
text-align: center;
line-height: 36rpx;
position: absolute;
bottom: 0%;
background: rgba(000, 000, 000, 0.5);
border-radius: 0rpx 0rpx 4rpx 4rpx;
}
}
}
.sm {
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 26rpx;
color: #979797;
white-space: pre-wrap;
}
.imgflex {
width: 610rpx;
position: absolute;
bottom: 60rpx;
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 20rpx;
color: #9da0ae;
text-align: center;
.img {
width: 54rpx;
height: 8rpx;
margin: 0rpx 10rpx;
}
.i2 {
transform: scaleX(-1);
}
}
}
.footer-con {
position: fixed;
width: 100%;
bottom: 0;
background-color: #fff;
padding: 22rpx 30rpx;
padding-bottom: constant(safe-area-inset-bottom);
padding-bottom: env(safe-area-inset-bottom);
z-index: 9;
box-sizing: border-box;
border: 1px solid #fff;
.l_btn {
.x {
width: 50rpx;
position: relative;
image {
width: 48rpx;
height: 48rpx;
}
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 24rpx;
color: #5c5d70;
.zf_btns {
position: absolute;
width: 50rpx;
height: 50rpx;
right: 0%;
top: 0%;
opacity: 0;
}
}
}
.f-btn {
line-height: 100rpx;
font-size: 32rpx;
color: #fff;
height: 100rpx;
background: linear-gradient(270deg, #ff6f07 0%, #ffa666 100%);
border-radius: 4rpx;
text-align: center;
width: 440rpx;
}
}
.preview-container {
position: fixed;
top: 0;
left: 0;
width: 100%;
height: 100%;
background-color: #000;
z-index: 999;
swiper {
width: 100%;
height: 100%;
}
swiper-item {
width: 100%;
height: 100%;
display: flex;
align-items: center;
justify-content: center;
}
.media-item {
width: 100%;
height: 100%;
display: flex;
align-items: center;
justify-content: center;
}
.media-img {
max-width: 100%;
max-height: 100%;
object-fit: contain;
}
.media-video {
width: 100%;
height: 80%;
object-fit: contain;
}
.page-indicator {
position: absolute;
bottom: 40rpx;
left: 50%;
transform: translateX(-50%);
color: white;
font-size: 28rpx;
z-index: 10;
}
}
.canvasCss {
width: 750rpx;
text-align: center;
.icons {
position: absolute;
right: 30rpx;
top: -50rpx;
}
image {
width: 600rpx;
height: 1100rpx;
}
.btns {
width: 88rpx;
font-family: PingFang SC, PingFang SC;
font-weight: 500;
font-size: 24rpx;
color: #ffffff;
text-align: center;
margin: 0rpx auto;
.b {
width: 88rpx;
height: 88rpx;
background: #ffffff;
border-radius: 60rpx 60rpx 60rpx 60rpx;
margin: 30rpx auto 10rpx;
image {
width: 48rpx;
height: 48rpx;
}
}
}
}
</style>
9.canvas方法封装
canvasUtils.js
/**
* 在 Canvas 上绘制带圆角的图片（常用于头像、二维码等）
* 通过 clip 裁剪出圆角矩形区域，再绘制图片
* @param {Object} ctx - canvas 上下文对象（由 uni.createCanvasContext 创建）
* @param {string} img - 图片本地路径（必须是 getImageInfo 返回的 path）
* @param {number} x - 图片左上角 X 坐标（单位：px，已按比例缩放）
* @param {number} y - 图片左上角 Y 坐标
* @param {number} width - 图片绘制宽度
* @param {number} height - 图片绘制高度
* @param {number} radius - 圆角半径（建议 ≤ min(width, height)/2）
* @param {boolean} shadow - 是否添加红色阴影（用于特殊效果，如印章）
*/
export function drawRoundedImage(ctx, img, x, y, width, height, radius, shadow = false) {
ctx.save()
ctx.beginPath()
// 左上角
ctx.moveTo(x + radius, y)
// 右上角
ctx.lineTo(x + width - radius, y)
ctx.arc(x + width - radius, y + radius, radius, Math.PI * 1.5, Math.PI * 2)
// 右下角
ctx.lineTo(x + width, y + height - radius)
ctx.arc(x + width - radius, y + height - radius, radius, 0, Math.PI * 0.5)
// 左下角
ctx.lineTo(x + radius, y + height)
ctx.arc(x + radius, y + height - radius, radius, Math.PI * 0.5, Math.PI)
// 左上角闭合
ctx.lineTo(x, y + radius)
ctx.arc(x + radius, y + radius, radius, Math.PI, Math.PI * 1.5)
ctx.closePath()
if (shadow) {
ctx.shadowBlur = 20
ctx.shadowColor = 'red'
}
ctx.clip() // 裁剪出圆角区域
ctx.drawImage(img, x, y, width, height)
ctx.restore()
}
/**
* 绘制带圆角的纯色/渐变矩形（常用于背景、卡片容器）
* @param {Object} ctx - canvas 上下文
* @param {number} x - 矩形左上角 X
* @param {number} y - 矩形左上角 Y
* @param {number} width - 宽度
* @param {number} height - 高度
* @param {number} radius - 圆角半径
* @param {string|CanvasGradient} fillStyle - 填充样式（颜色字符串或渐变对象）
*/
export function drawRoundedRect(ctx, x, y, width, height, radius, fillStyle) {
ctx.save()
ctx.beginPath()
ctx.moveTo(x + radius, y)
ctx.lineTo(x + width - radius, y)
ctx.arc(x + width - radius, y + radius, radius, Math.PI * 1.5, Math.PI * 2)
ctx.lineTo(x + width, y + height - radius)
ctx.arc(x + width - radius, y + height - radius, radius, 0, Math.PI * 0.5)
ctx.lineTo(x + radius, y + height)
ctx.arc(x + radius, y + height - radius, radius, Math.PI * 0.5, Math.PI)
ctx.lineTo(x, y + radius)
ctx.arc(x + radius, y + radius, radius, Math.PI, Math.PI * 1.5)
ctx.closePath()
ctx.fillStyle = fillStyle
ctx.fill()
ctx.restore()
}
/**
* 对单行文本进行自动省略（超出 maxWidth 显示 ...）
* @param {Object} ctx - canvas 上下文
* @param {string} str - 原始文本
* @param {number} maxWidth - 最大允许宽度（px）
* @returns {string} 截断后的文本（可能带 …）
*/
export function truncateText(ctx, str, maxWidth) {
const ellipsis = '…'
const ellipsisWidth = ctx.measureText(ellipsis).width
let currentWidth = ctx.measureText(str).width
if (currentWidth <= maxWidth || maxWidth <= ellipsisWidth) {
return str
}
let len = str.length
while (currentWidth >= maxWidth - ellipsisWidth && len > 0) {
len--
str = str.slice(0, len)
currentWidth = ctx.measureText(str).width
}
return str + ellipsis
}
/**
* 绘制单行文本（支持自动省略）
* @param {Object} ctx - canvas 上下文
* @param {string} font - 字体样式，如 '18px Arial'
* @param {string} align - 对齐方式 ('left' | 'center' | 'right')
* @param {string} fillStyle - 文字颜色
* @param {string} text - 要绘制的文本
* @param {number} x - 绘制 X 坐标
* @param {number} y - 绘制 Y 坐标（基线位置）
* @param {number|null} maxWidth - 最大宽度，超过则省略（可选）
*/
export function drawText(ctx, font, align, fillStyle, text, x, y, maxWidth = null) {
ctx.font = font;
ctx.textAlign = align; // ← 直接使用原生对齐！
ctx.textBaseline = 'alphabetic';
ctx.fillStyle = fillStyle;
let finalText = text;
if (maxWidth != null) {
finalText = truncateText(ctx, text, maxWidth);
}
ctx.fillText(finalText, x, y); // x 就是 align 的参考点
}
/**
* 绘制多行自动换行文本（适合长介绍、描述）
* @param {Object} ctx - canvas 上下文
* @param {string} text - 原始文本（可为空）
* @param {number} x - 起始 X 坐标
* @param {number} y - 起始 Y 坐标（第一行顶部位置）
* @param {number} maxWidth - 每行最大宽度
* @param {number} lineHeight - 行高（默认 20px）
* @param {string} font - 字体（默认 '13px Arial, "PingFang SC"'）
* @param {string} color - 文字颜色（默认 '#000000'）
*/
export function drawWrappedText(
ctx,
text,
x,
y,
maxWidth,
lineHeight = 20,
font = '13px Arial, "PingFang SC"',
color = '#000000'
) {
const content = (text || '未设置个性签名').replace(/\r\n/g, '\n'); // 兼容 Windows 换行
const paragraphs = content.split('\n'); // 先按换行符分段
const lines = [];
ctx.font = font;
// 对每个段落单独处理自动换行
for (const paragraph of paragraphs) {
if (paragraph === '') {
lines.push(''); // 保留空行
continue;
}
let line = '';
const chars = paragraph.split('');
for (const char of chars) {
const testLine = line + char;
const testWidth = ctx.measureText(testLine).width;
if (testWidth <= maxWidth) {
line = testLine;
} else {
if (line === '') {
// 单个字符超宽，强制放入
lines.push(char);
line = '';
} else {
lines.push(line);
line = char;
}
}
}
if (line) lines.push(line);
}
// 绘制所有行
ctx.textAlign = 'left';
ctx.fillStyle = color;
lines.forEach((lineText, index) => {
ctx.fillText(lineText, x, y + (index + 1) * lineHeight);
});
}
// 绘制一条线
export function drawLine(ctx, startX = 50, startY = 50, endX = 250, endY = 50, color = '#EEEEEE', width = 1) {
if (!ctx) return; // 确保上下文存在
ctx.beginPath(); // 开始路径
ctx.moveTo(startX, startY); // 起点
ctx.lineTo(endX, endY); // 终点
ctx.strokeStyle = color; // 线条颜色
ctx.lineWidth = width; // 线条宽度
ctx.stroke(); // 绘制
ctx.closePath(); // 关闭路径
}
// 绘制水印
export function drawWatermark(ctx, width, height, text = 'SAMPLE', color = '#000', alpha = 0.05) {
ctx.save();
// 下面透明度不行 就换成这样
ctx.fillStyle = 'rgba(000,000,000,0.05)'; // ← 关键：颜色自带透明度
// 设置透明度
ctx.globalAlpha = alpha;
// 设置字体（建议粗体更清晰）
ctx.font = ' 12px Arial';
ctx.fillStyle = color;
ctx.textAlign = 'center';
ctx.textBaseline = 'middle';
// 可选：旋转水印（45度斜向）
const angle = (-25 * Math.PI) / 180; // 转为弧度（-25度）
ctx.translate(width / 2, height / 2);
ctx.rotate(angle);
// 计算水印间距（根据文字长度动态调整）
const textWidth = ctx.measureText(text).width;
const spacingX = textWidth * 1.5; // 水平间距
const spacingY = 100; // 垂直间距
// 铺满整个区域
for (let x = -width; x < width; x += spacingX) {
for (let y = -height; y < height; y += spacingY) {
ctx.fillText(text, x, y);
}
}
ctx.restore(); // 恢复状态（重置透明度、旋转等）
}
/**
* 绘制带边框的文字标签（矩形左上角为 (x, y)）
*
* @param {Object} ctx
* @param {string} text - 文字内容
* @param {number} x - 矩形左上角 X
* @param {number} y - 矩形左上角 Y
* @param {string} font - 字体
* @param {string} textColor - 文字颜色
* @param {string} borderColor - 边框颜色
* @param {string} fillColor - 背景色（支持 'transparent'）
* @param {number} paddingX - 水平内边距
* @param {number} paddingY - 垂直内边距
* @param {number} borderWidth - 边框宽度
*/
export function drawTextWithBorderBox(
ctx,
text,
x,
y,
font = '14px Arial',
textColor = '#000000',
borderColor = '#CCCCCC',
fillColor = '#F5F5F5',
paddingX = 12,
paddingY = 6,
borderWidth = 0.5
) {
ctx.font = font
const textWidth = ctx.measureText(text).width
// 高度估算：使用字体大小近似（更准确可用 lineHeight）
const fontSize = parseFloat(font) || 14
const rectHeight = fontSize + paddingY * 2
const rectWidth = textWidth + paddingX * 2
// 1. 填充背景
if (fillColor !== 'transparent') {
ctx.fillStyle = fillColor
ctx.fillRect(x, y, rectWidth, rectHeight)
}
// 2. 绘制边框
ctx.strokeStyle = borderColor
ctx.lineWidth = borderWidth
ctx.strokeRect(x, y, rectWidth, rectHeight)
// 3. 绘制文字（左对齐，垂直居中）
ctx.fillStyle = textColor
ctx.textAlign = 'left'
ctx.textBaseline = 'middle'
const textX = x + paddingX
const textY = y + rectHeight / 2
ctx.fillText(text, textX, textY)
}
10.uqrcode.js
let uQRCode = {};
(function() {
//---------------------------------------------------------------------
// QRCode for JavaScript
//
// Copyright (c) 2009 Kazuhiko Arase
//
// URL: http://www.d-project.com/
//
// Licensed under the MIT license:
// http://www.opensource.org/licenses/mit-license.php
//
// The word "QR Code" is registered trademark of
// DENSO WAVE INCORPORATED
// http://www.denso-wave.com/qrcode/faqpatent-e.html
//
//---------------------------------------------------------------------
//---------------------------------------------------------------------
// QR8bitByte
//---------------------------------------------------------------------
function QR8bitByte(data) {
this.mode = QRMode.MODE_8BIT_BYTE;
this.data = data;
}
QR8bitByte.prototype = {
getLength: function(buffer) {
return this.data.length;
},
write: function(buffer) {
for (var i = 0; i < this.data.length; i++) {
// not JIS ...
buffer.put(this.data.charCodeAt(i), 8);
}
}
};
//---------------------------------------------------------------------
// QRCode
//---------------------------------------------------------------------
function QRCode(typeNumber, errorCorrectLevel) {
this.typeNumber = typeNumber;
this.errorCorrectLevel = errorCorrectLevel;
this.modules = null;
this.moduleCount = 0;
this.dataCache = null;
this.dataList = new Array();
}
QRCode.prototype = {
addData: function(data) {
var newData = new QR8bitByte(data);
this.dataList.push(newData);
this.dataCache = null;
},
isDark: function(row, col) {
if (row < 0 || this.moduleCount <= row || col < 0 || this.moduleCount <= col) {
throw new Error(row + "," + col);
}
return this.modules[row][col];
},
getModuleCount: function() {
return this.moduleCount;
},
make: function() {
// Calculate automatically typeNumber if provided is < 1
if (this.typeNumber < 1) {
var typeNumber = 1;
for (typeNumber = 1; typeNumber < 40; typeNumber++) {
var rsBlocks = QRRSBlock.getRSBlocks(typeNumber, this.errorCorrectLevel);
var buffer = new QRBitBuffer();
var totalDataCount = 0;
for (var i = 0; i < rsBlocks.length; i++) {
totalDataCount += rsBlocks[i].dataCount;
}
for (var i = 0; i < this.dataList.length; i++) {
var data = this.dataList[i];
buffer.put(data.mode, 4);
buffer.put(data.getLength(), QRUtil.getLengthInBits(data.mode, typeNumber));
data.write(buffer);
}
if (buffer.getLengthInBits() <= totalDataCount * 8)
break;
}
this.typeNumber = typeNumber;
}
this.makeImpl(false, this.getBestMaskPattern());
},
makeImpl: function(test, maskPattern) {
this.moduleCount = this.typeNumber * 4 + 17;
this.modules = new Array(this.moduleCount);
for (var row = 0; row < this.moduleCount; row++) {
this.modules[row] = new Array(this.moduleCount);
for (var col = 0; col < this.moduleCount; col++) {
this.modules[row][col] = null; //(col + row) % 3;
}
}
this.setupPositionProbePattern(0, 0);
this.setupPositionProbePattern(this.moduleCount - 7, 0);
this.setupPositionProbePattern(0, this.moduleCount - 7);
this.setupPositionAdjustPattern();
this.setupTimingPattern();
this.setupTypeInfo(test, maskPattern);
if (this.typeNumber >= 7) {
this.setupTypeNumber(test);
}
if (this.dataCache == null) {
this.dataCache = QRCode.createData(this.typeNumber, this.errorCorrectLevel, this.dataList);
}
this.mapData(this.dataCache, maskPattern);
},
setupPositionProbePattern: function(row, col) {
for (var r = -1; r <= 7; r++) {
if (row + r <= -1 || this.moduleCount <= row + r) continue;
for (var c = -1; c <= 7; c++) {
if (col + c <= -1 || this.moduleCount <= col + c) continue;
if ((0 <= r && r <= 6 && (c == 0 || c == 6)) ||
(0 <= c && c <= 6 && (r == 0 || r == 6)) ||
(2 <= r && r <= 4 && 2 <= c && c <= 4)) {
this.modules[row + r][col + c] = true;
} else {
this.modules[row + r][col + c] = false;
}
}
}
},
getBestMaskPattern: function() {
var minLostPoint = 0;
var pattern = 0;
for (var i = 0; i < 8; i++) {
this.makeImpl(true, i);
var lostPoint = QRUtil.getLostPoint(this);
if (i == 0 || minLostPoint > lostPoint) {
minLostPoint = lostPoint;
pattern = i;
}
}
return pattern;
},
createMovieClip: function(target_mc, instance_name, depth) {
var qr_mc = target_mc.createEmptyMovieClip(instance_name, depth);
var cs = 1;
this.make();
for (var row = 0; row < this.modules.length; row++) {
var y = row * cs;
for (var col = 0; col < this.modules[row].length; col++) {
var x = col * cs;
var dark = this.modules[row][col];
if (dark) {
qr_mc.beginFill(0, 100);
qr_mc.moveTo(x, y);
qr_mc.lineTo(x + cs, y);
qr_mc.lineTo(x + cs, y + cs);
qr_mc.lineTo(x, y + cs);
qr_mc.endFill();
}
}
}
return qr_mc;
},
setupTimingPattern: function() {
for (var r = 8; r < this.moduleCount - 8; r++) {
if (this.modules[r][6] != null) {
continue;
}
this.modules[r][6] = (r % 2 == 0);
}
for (var c = 8; c < this.moduleCount - 8; c++) {
if (this.modules[6][c] != null) {
continue;
}
this.modules[6][c] = (c % 2 == 0);
}
},
setupPositionAdjustPattern: function() {
var pos = QRUtil.getPatternPosition(this.typeNumber);
for (var i = 0; i < pos.length; i++) {
for (var j = 0; j < pos.length; j++) {
var row = pos[i];
var col = pos[j];
if (this.modules[row][col] != null) {
continue;
}
for (var r = -2; r <= 2; r++) {
for (var c = -2; c <= 2; c++) {
if (r == -2 || r == 2 || c == -2 || c == 2 ||
(r == 0 && c == 0)) {
this.modules[row + r][col + c] = true;
} else {
this.modules[row + r][col + c] = false;
}
}
}
}
}
},
setupTypeNumber: function(test) {
var bits = QRUtil.getBCHTypeNumber(this.typeNumber);
for (var i = 0; i < 18; i++) {
var mod = (!test && ((bits >> i) & 1) == 1);
this.modules[Math.floor(i / 3)][i % 3 + this.moduleCount - 8 - 3] = mod;
}
for (var i = 0; i < 18; i++) {
var mod = (!test && ((bits >> i) & 1) == 1);
this.modules[i % 3 + this.moduleCount - 8 - 3][Math.floor(i / 3)] = mod;
}
},
setupTypeInfo: function(test, maskPattern) {
var data = (this.errorCorrectLevel << 3) | maskPattern;
var bits = QRUtil.getBCHTypeInfo(data);
// vertical
for (var i = 0; i < 15; i++) {
var mod = (!test && ((bits >> i) & 1) == 1);
if (i < 6) {
this.modules[i][8] = mod;
} else if (i < 8) {
this.modules[i + 1][8] = mod;
} else {
this.modules[this.moduleCount - 15 + i][8] = mod;
}
}
// horizontal
for (var i = 0; i < 15; i++) {
var mod = (!test && ((bits >> i) & 1) == 1);
if (i < 8) {
this.modules[8][this.moduleCount - i - 1] = mod;
} else if (i < 9) {
this.modules[8][15 - i - 1 + 1] = mod;
} else {
this.modules[8][15 - i - 1] = mod;
}
}
// fixed module
this.modules[this.moduleCount - 8][8] = (!test);
},
mapData: function(data, maskPattern) {
var inc = -1;
var row = this.moduleCount - 1;
var bitIndex = 7;
var byteIndex = 0;
for (var col = this.moduleCount - 1; col > 0; col -= 2) {
if (col == 6) col--;
while (true) {
for (var c = 0; c < 2; c++) {
if (this.modules[row][col - c] == null) {
var dark = false;
if (byteIndex < data.length) {
dark = (((data[byteIndex] >>> bitIndex) & 1) == 1);
}
var mask = QRUtil.getMask(maskPattern, row, col - c);
if (mask) {
dark = !dark;
}
this.modules[row][col - c] = dark;
bitIndex--;
if (bitIndex == -1) {
byteIndex++;
bitIndex = 7;
}
}
}
row += inc;
if (row < 0 || this.moduleCount <= row) {
row -= inc;
inc = -inc;
break;
}
}
}
}
};
QRCode.PAD0 = 0xEC;
QRCode.PAD1 = 0x11;
QRCode.createData = function(typeNumber, errorCorrectLevel, dataList) {
var rsBlocks = QRRSBlock.getRSBlocks(typeNumber, errorCorrectLevel);
var buffer = new QRBitBuffer();
for (var i = 0; i < dataList.length; i++) {
var data = dataList[i];
buffer.put(data.mode, 4);
buffer.put(data.getLength(), QRUtil.getLengthInBits(data.mode, typeNumber));
data.write(buffer);
}
// calc num max data.
var totalDataCount = 0;
for (var i = 0; i < rsBlocks.length; i++) {
totalDataCount += rsBlocks[i].dataCount;
}
if (buffer.getLengthInBits() > totalDataCount * 8) {
throw new Error("code length overflow. (" +
buffer.getLengthInBits() +
">" +
totalDataCount * 8 +
")");
}
// end code
if (buffer.getLengthInBits() + 4 <= totalDataCount * 8) {
buffer.put(0, 4);
}
// padding
while (buffer.getLengthInBits() % 8 != 0) {
buffer.putBit(false);
}
// padding
while (true) {
if (buffer.getLengthInBits() >= totalDataCount * 8) {
break;
}
buffer.put(QRCode.PAD0, 8);
if (buffer.getLengthInBits() >= totalDataCount * 8) {
break;
}
buffer.put(QRCode.PAD1, 8);
}
return QRCode.createBytes(buffer, rsBlocks);
}
QRCode.createBytes = function(buffer, rsBlocks) {
var offset = 0;
var maxDcCount = 0;
var maxEcCount = 0;
var dcdata = new Array(rsBlocks.length);
var ecdata = new Array(rsBlocks.length);
for (var r = 0; r < rsBlocks.length; r++) {
var dcCount = rsBlocks[r].dataCount;
var ecCount = rsBlocks[r].totalCount - dcCount;
maxDcCount = Math.max(maxDcCount, dcCount);
maxEcCount = Math.max(maxEcCount, ecCount);
dcdata[r] = new Array(dcCount);
for (var i = 0; i < dcdata[r].length; i++) {
dcdata[r][i] = 0xff & buffer.buffer[i + offset];
}
offset += dcCount;
var rsPoly = QRUtil.getErrorCorrectPolynomial(ecCount);
var rawPoly = new QRPolynomial(dcdata[r], rsPoly.getLength() - 1);
var modPoly = rawPoly.mod(rsPoly);
ecdata[r] = new Array(rsPoly.getLength() - 1);
for (var i = 0; i < ecdata[r].length; i++) {
var modIndex = i + modPoly.getLength() - ecdata[r].length;
ecdata[r][i] = (modIndex >= 0) ? modPoly.get(modIndex) : 0;
}
}
var totalCodeCount = 0;
for (var i = 0; i < rsBlocks.length; i++) {
totalCodeCount += rsBlocks[i].totalCount;
}
var data = new Array(totalCodeCount);
var index = 0;
for (var i = 0; i < maxDcCount; i++) {
for (var r = 0; r < rsBlocks.length; r++) {
if (i < dcdata[r].length) {
data[index++] = dcdata[r][i];
}
}
}
for (var i = 0; i < maxEcCount; i++) {
for (var r = 0; r < rsBlocks.length; r++) {
if (i < ecdata[r].length) {
data[index++] = ecdata[r][i];
}
}
}
return data;
}
//---------------------------------------------------------------------
// QRMode
//---------------------------------------------------------------------
var QRMode = {
MODE_NUMBER: 1 << 0,
MODE_ALPHA_NUM: 1 << 1,
MODE_8BIT_BYTE: 1 << 2,
MODE_KANJI: 1 << 3
};
//---------------------------------------------------------------------
// QRErrorCorrectLevel
//---------------------------------------------------------------------
var QRErrorCorrectLevel = {
L: 1,
M: 0,
Q: 3,
H: 2
};
//---------------------------------------------------------------------
// QRMaskPattern
//---------------------------------------------------------------------
var QRMaskPattern = {
PATTERN000: 0,
PATTERN001: 1,
PATTERN010: 2,
PATTERN011: 3,
PATTERN100: 4,
PATTERN101: 5,
PATTERN110: 6,
PATTERN111: 7
};
//---------------------------------------------------------------------
// QRUtil
//---------------------------------------------------------------------
var QRUtil = {
PATTERN_POSITION_TABLE: [
[],
[6, 18],
[6, 22],
[6, 26],
[6, 30],
[6, 34],
[6, 22, 38],
[6, 24, 42],
[6, 26, 46],
[6, 28, 50],
[6, 30, 54],
[6, 32, 58],
[6, 34, 62],
[6, 26, 46, 66],
[6, 26, 48, 70],
[6, 26, 50, 74],
[6, 30, 54, 78],
[6, 30, 56, 82],
[6, 30, 58, 86],
[6, 34, 62, 90],
[6, 28, 50, 72, 94],
[6, 26, 50, 74, 98],
[6, 30, 54, 78, 102],
[6, 28, 54, 80, 106],
[6, 32, 58, 84, 110],
[6, 30, 58, 86, 114],
[6, 34, 62, 90, 118],
[6, 26, 50, 74, 98, 122],
[6, 30, 54, 78, 102, 126],
[6, 26, 52, 78, 104, 130],
[6, 30, 56, 82, 108, 134],
[6, 34, 60, 86, 112, 138],
[6, 30, 58, 86, 114, 142],
[6, 34, 62, 90, 118, 146],
[6, 30, 54, 78, 102, 126, 150],
[6, 24, 50, 76, 102, 128, 154],
[6, 28, 54, 80, 106, 132, 158],
[6, 32, 58, 84, 110, 136, 162],
[6, 26, 54, 82, 110, 138, 166],
[6, 30, 58, 86, 114, 142, 170]
],
G15: (1 << 10) | (1 << 8) | (1 << 5) | (1 << 4) | (1 << 2) | (1 << 1) | (1 << 0),
G18: (1 << 12) | (1 << 11) | (1 << 10) | (1 << 9) | (1 << 8) | (1 << 5) | (1 << 2) | (1 << 0),
G15_MASK: (1 << 14) | (1 << 12) | (1 << 10) | (1 << 4) | (1 << 1),
getBCHTypeInfo: function(data) {
var d = data << 10;
while (QRUtil.getBCHDigit(d) - QRUtil.getBCHDigit(QRUtil.G15) >= 0) {
d ^= (QRUtil.G15 << (QRUtil.getBCHDigit(d) - QRUtil.getBCHDigit(QRUtil.G15)));
}
return ((data << 10) | d) ^ QRUtil.G15_MASK;
},
getBCHTypeNumber: function(data) {
var d = data << 12;
while (QRUtil.getBCHDigit(d) - QRUtil.getBCHDigit(QRUtil.G18) >= 0) {
d ^= (QRUtil.G18 << (QRUtil.getBCHDigit(d) - QRUtil.getBCHDigit(QRUtil.G18)));
}
return (data << 12) | d;
},
getBCHDigit: function(data) {
var digit = 0;
while (data != 0) {
digit++;
data >>>= 1;
}
return digit;
},
getPatternPosition: function(typeNumber) {
return QRUtil.PATTERN_POSITION_TABLE[typeNumber - 1];
},
getMask: function(maskPattern, i, j) {
switch (maskPattern) {
case QRMaskPattern.PATTERN000:
return (i + j) % 2 == 0;
case QRMaskPattern.PATTERN001:
return i % 2 == 0;
case QRMaskPattern.PATTERN010:
return j % 3 == 0;
case QRMaskPattern.PATTERN011:
return (i + j) % 3 == 0;
case QRMaskPattern.PATTERN100:
return (Math.floor(i / 2) + Math.floor(j / 3)) % 2 == 0;
case QRMaskPattern.PATTERN101:
return (i * j) % 2 + (i * j) % 3 == 0;
case QRMaskPattern.PATTERN110:
return ((i * j) % 2 + (i * j) % 3) % 2 == 0;
case QRMaskPattern.PATTERN111:
return ((i * j) % 3 + (i + j) % 2) % 2 == 0;
default:
throw new Error("bad maskPattern:" + maskPattern);
}
},
getErrorCorrectPolynomial: function(errorCorrectLength) {
var a = new QRPolynomial([1], 0);
for (var i = 0; i < errorCorrectLength; i++) {
a = a.multiply(new QRPolynomial([1, QRMath.gexp(i)], 0));
}
return a;
},
getLengthInBits: function(mode, type) {
if (1 <= type && type < 10) {
// 1 - 9
switch (mode) {
case QRMode.MODE_NUMBER:
return 10;
case QRMode.MODE_ALPHA_NUM:
return 9;
case QRMode.MODE_8BIT_BYTE:
return 8;
case QRMode.MODE_KANJI:
return 8;
default:
throw new Error("mode:" + mode);
}
} else if (type < 27) {
// 10 - 26
switch (mode) {
case QRMode.MODE_NUMBER:
return 12;
case QRMode.MODE_ALPHA_NUM:
return 11;
case QRMode.MODE_8BIT_BYTE:
return 16;
case QRMode.MODE_KANJI:
return 10;
default:
throw new Error("mode:" + mode);
}
} else if (type < 41) {
// 27 - 40
switch (mode) {
case QRMode.MODE_NUMBER:
return 14;
case QRMode.MODE_ALPHA_NUM:
return 13;
case QRMode.MODE_8BIT_BYTE:
return 16;
case QRMode.MODE_KANJI:
return 12;
default:
throw new Error("mode:" + mode);
}
} else {
throw new Error("type:" + type);
}
},
getLostPoint: function(qrCode) {
var moduleCount = qrCode.getModuleCount();
var lostPoint = 0;
// LEVEL1
for (var row = 0; row < moduleCount; row++) {
for (var col = 0; col < moduleCount; col++) {
var sameCount = 0;
var dark = qrCode.isDark(row, col);
for (var r = -1; r <= 1; r++) {
if (row + r < 0 || moduleCount <= row + r) {
continue;
}
for (var c = -1; c <= 1; c++) {
if (col + c < 0 || moduleCount <= col + c) {
continue;
}
if (r == 0 && c == 0) {
continue;
}
if (dark == qrCode.isDark(row + r, col + c)) {
sameCount++;
}
}
}
if (sameCount > 5) {
lostPoint += (3 + sameCount - 5);
}
}
}
// LEVEL2
for (var row = 0; row < moduleCount - 1; row++) {
for (var col = 0; col < moduleCount - 1; col++) {
var count = 0;
if (qrCode.isDark(row, col)) count++;
if (qrCode.isDark(row + 1, col)) count++;
if (qrCode.isDark(row, col + 1)) count++;
if (qrCode.isDark(row + 1, col + 1)) count++;
if (count == 0 || count == 4) {
lostPoint += 3;
}
}
}
// LEVEL3
for (var row = 0; row < moduleCount; row++) {
for (var col = 0; col < moduleCount - 6; col++) {
if (qrCode.isDark(row, col) &&
!qrCode.isDark(row, col + 1) &&
qrCode.isDark(row, col + 2) &&
qrCode.isDark(row, col + 3) &&
qrCode.isDark(row, col + 4) &&
!qrCode.isDark(row, col + 5) &&
qrCode.isDark(row, col + 6)) {
lostPoint += 40;
}
}
}
for (var col = 0; col < moduleCount; col++) {
for (var row = 0; row < moduleCount - 6; row++) {
if (qrCode.isDark(row, col) &&
!qrCode.isDark(row + 1, col) &&
qrCode.isDark(row + 2, col) &&
qrCode.isDark(row + 3, col) &&
qrCode.isDark(row + 4, col) &&
!qrCode.isDark(row + 5, col) &&
qrCode.isDark(row + 6, col)) {
lostPoint += 40;
}
}
}
// LEVEL4
var darkCount = 0;
for (var col = 0; col < moduleCount; col++) {
for (var row = 0; row < moduleCount; row++) {
if (qrCode.isDark(row, col)) {
darkCount++;
}
}
}
var ratio = Math.abs(100 * darkCount / moduleCount / moduleCount - 50) / 5;
lostPoint += ratio * 10;
return lostPoint;
}
};
//---------------------------------------------------------------------
// QRMath
//---------------------------------------------------------------------
var QRMath = {
glog: function(n) {
if (n < 1) {
throw new Error("glog(" + n + ")");
}
return QRMath.LOG_TABLE[n];
},
gexp: function(n) {
while (n < 0) {
n += 255;
}
while (n >= 256) {
n -= 255;
}
return QRMath.EXP_TABLE[n];
},
EXP_TABLE: new Array(256),
LOG_TABLE: new Array(256)
};
for (var i = 0; i < 8; i++) {
QRMath.EXP_TABLE[i] = 1 << i;
}
for (var i = 8; i < 256; i++) {
QRMath.EXP_TABLE[i] = QRMath.EXP_TABLE[i - 4] ^
QRMath.EXP_TABLE[i - 5] ^
QRMath.EXP_TABLE[i - 6] ^
QRMath.EXP_TABLE[i - 8];
}
for (var i = 0; i < 255; i++) {
QRMath.LOG_TABLE[QRMath.EXP_TABLE[i]] = i;
}
//---------------------------------------------------------------------
// QRPolynomial
//---------------------------------------------------------------------
function QRPolynomial(num, shift) {
if (num.length == undefined) {
throw new Error(num.length + "/" + shift);
}
var offset = 0;
while (offset < num.length && num[offset] == 0) {
offset++;
}
this.num = new Array(num.length - offset + shift);
for (var i = 0; i < num.length - offset; i++) {
this.num[i] = num[i + offset];
}
}
QRPolynomial.prototype = {
get: function(index) {
return this.num[index];
},
getLength: function() {
return this.num.length;
},
multiply: function(e) {
var num = new Array(this.getLength() + e.getLength() - 1);
for (var i = 0; i < this.getLength(); i++) {
for (var j = 0; j < e.getLength(); j++) {
num[i + j] ^= QRMath.gexp(QRMath.glog(this.get(i)) + QRMath.glog(e.get(j)));
}
}
return new QRPolynomial(num, 0);
},
mod: function(e) {
if (this.getLength() - e.getLength() < 0) {
return this;
}
var ratio = QRMath.glog(this.get(0)) - QRMath.glog(e.get(0));
var num = new Array(this.getLength());
for (var i = 0; i < this.getLength(); i++) {
num[i] = this.get(i);
}
for (var i = 0; i < e.getLength(); i++) {
num[i] ^= QRMath.gexp(QRMath.glog(e.get(i)) + ratio);
}
// recursive call
return new QRPolynomial(num, 0).mod(e);
}
};
//---------------------------------------------------------------------
// QRRSBlock
//---------------------------------------------------------------------
function QRRSBlock(totalCount, dataCount) {
this.totalCount = totalCount;
this.dataCount = dataCount;
}
QRRSBlock.RS_BLOCK_TABLE = [
// L
// M
// Q
// H
// 1
[1, 26, 19],
[1, 26, 16],
[1, 26, 13],
[1, 26, 9],
// 2
[1, 44, 34],
[1, 44, 28],
[1, 44, 22],
[1, 44, 16],
// 3
[1, 70, 55],
[1, 70, 44],
[2, 35, 17],
[2, 35, 13],
// 4
[1, 100, 80],
[2, 50, 32],
[2, 50, 24],
[4, 25, 9],
// 5
[1, 134, 108],
[2, 67, 43],
[2, 33, 15, 2, 34, 16],
[2, 33, 11, 2, 34, 12],
// 6
[2, 86, 68],
[4, 43, 27],
[4, 43, 19],
[4, 43, 15],
// 7
[2, 98, 78],
[4, 49, 31],
[2, 32, 14, 4, 33, 15],
[4, 39, 13, 1, 40, 14],
// 8
[2, 121, 97],
[2, 60, 38, 2, 61, 39],
[4, 40, 18, 2, 41, 19],
[4, 40, 14, 2, 41, 15],
// 9
[2, 146, 116],
[3, 58, 36, 2, 59, 37],
[4, 36, 16, 4, 37, 17],
[4, 36, 12, 4, 37, 13],
// 10
[2, 86, 68, 2, 87, 69],
[4, 69, 43, 1, 70, 44],
[6, 43, 19, 2, 44, 20],
[6, 43, 15, 2, 44, 16],
// 11
[4, 101, 81],
[1, 80, 50, 4, 81, 51],
[4, 50, 22, 4, 51, 23],
[3, 36, 12, 8, 37, 13],
// 12
[2, 116, 92, 2, 117, 93],
[6, 58, 36, 2, 59, 37],
[4, 46, 20, 6, 47, 21],
[7, 42, 14, 4, 43, 15],
// 13
[4, 133, 107],
[8, 59, 37, 1, 60, 38],
[8, 44, 20, 4, 45, 21],
[12, 33, 11, 4, 34, 12],
// 14
[3, 145, 115, 1, 146, 116],
[4, 64, 40, 5, 65, 41],
[11, 36, 16, 5, 37, 17],
[11, 36, 12, 5, 37, 13],
// 15
[5, 109, 87, 1, 110, 88],
[5, 65, 41, 5, 66, 42],
[5, 54, 24, 7, 55, 25],
[11, 36, 12],
// 16
[5, 122, 98, 1, 123, 99],
[7, 73, 45, 3, 74, 46],
[15, 43, 19, 2, 44, 20],
[3, 45, 15, 13, 46, 16],
// 17
[1, 135, 107, 5, 136, 108],
[10, 74, 46, 1, 75, 47],
[1, 50, 22, 15, 51, 23],
[2, 42, 14, 17, 43, 15],
// 18
[5, 150, 120, 1, 151, 121],
[9, 69, 43, 4, 70, 44],
[17, 50, 22, 1, 51, 23],
[2, 42, 14, 19, 43, 15],
// 19
[3, 141, 113, 4, 142, 114],
[3, 70, 44, 11, 71, 45],
[17, 47, 21, 4, 48, 22],
[9, 39, 13, 16, 40, 14],
// 20
[3, 135, 107, 5, 136, 108],
[3, 67, 41, 13, 68, 42],
[15, 54, 24, 5, 55, 25],
[15, 43, 15, 10, 44, 16],
// 21
[4, 144, 116, 4, 145, 117],
[17, 68, 42],
[17, 50, 22, 6, 51, 23],
[19, 46, 16, 6, 47, 17],
// 22
[2, 139, 111, 7, 140, 112],
[17, 74, 46],
[7, 54, 24, 16, 55, 25],
[34, 37, 13],
// 23
[4, 151, 121, 5, 152, 122],
[4, 75, 47, 14, 76, 48],
[11, 54, 24, 14, 55, 25],
[16, 45, 15, 14, 46, 16],
// 24
[6, 147, 117, 4, 148, 118],
[6, 73, 45, 14, 74, 46],
[11, 54, 24, 16, 55, 25],
[30, 46, 16, 2, 47, 17],
// 25
[8, 132, 106, 4, 133, 107],
[8, 75, 47, 13, 76, 48],
[7, 54, 24, 22, 55, 25],
[22, 45, 15, 13, 46, 16],
// 26
[10, 142, 114, 2, 143, 115],
[19, 74, 46, 4, 75, 47],
[28, 50, 22, 6, 51, 23],
[33, 46, 16, 4, 47, 17],
// 27
[8, 152, 122, 4, 153, 123],
[22, 73, 45, 3, 74, 46],
[8, 53, 23, 26, 54, 24],
[12, 45, 15, 28, 46, 16],
// 28
[3, 147, 117, 10, 148, 118],
[3, 73, 45, 23, 74, 46],
[4, 54, 24, 31, 55, 25],
[11, 45, 15, 31, 46, 16],
// 29
[7, 146, 116, 7, 147, 117],
[21, 73, 45, 7, 74, 46],
[1, 53, 23, 37, 54, 24],
[19, 45, 15, 26, 46, 16],
// 30
[5, 145, 115, 10, 146, 116],
[19, 75, 47, 10, 76, 48],
[15, 54, 24, 25, 55, 25],
[23, 45, 15, 25, 46, 16],
// 31
[13, 145, 115, 3, 146, 116],
[2, 74, 46, 29, 75, 47],
[42, 54, 24, 1, 55, 25],
[23, 45, 15, 28, 46, 16],
// 32
[17, 145, 115],
[10, 74, 46, 23, 75, 47],
[10, 54, 24, 35, 55, 25],
[19, 45, 15, 35, 46, 16],
// 33
[17, 145, 115, 1, 146, 116],
[14, 74, 46, 21, 75, 47],
[29, 54, 24, 19, 55, 25],
[11, 45, 15, 46, 46, 16],
// 34
[13, 145, 115, 6, 146, 116],
[14, 74, 46, 23, 75, 47],
[44, 54, 24, 7, 55, 25],
[59, 46, 16, 1, 47, 17],
// 35
[12, 151, 121, 7, 152, 122],
[12, 75, 47, 26, 76, 48],
[39, 54, 24, 14, 55, 25],
[22, 45, 15, 41, 46, 16],
// 36
[6, 151, 121, 14, 152, 122],
[6, 75, 47, 34, 76, 48],
[46, 54, 24, 10, 55, 25],
[2, 45, 15, 64, 46, 16],
// 37
[17, 152, 122, 4, 153, 123],
[29, 74, 46, 14, 75, 47],
[49, 54, 24, 10, 55, 25],
[24, 45, 15, 46, 46, 16],
// 38
[4, 152, 122, 18, 153, 123],
[13, 74, 46, 32, 75, 47],
[48, 54, 24, 14, 55, 25],
[42, 45, 15, 32, 46, 16],
// 39
[20, 147, 117, 4, 148, 118],
[40, 75, 47, 7, 76, 48],
[43, 54, 24, 22, 55, 25],
[10, 45, 15, 67, 46, 16],
// 40
[19, 148, 118, 6, 149, 119],
[18, 75, 47, 31, 76, 48],
[34, 54, 24, 34, 55, 25],
[20, 45, 15, 61, 46, 16]
];
QRRSBlock.getRSBlocks = function(typeNumber, errorCorrectLevel) {
var rsBlock = QRRSBlock.getRsBlockTable(typeNumber, errorCorrectLevel);
if (rsBlock == undefined) {
throw new Error("bad rs block @ typeNumber:" + typeNumber + "/errorCorrectLevel:" + errorCorrectLevel);
}
var length = rsBlock.length / 3;
var list = new Array();
for (var i = 0; i < length; i++) {
var count = rsBlock[i * 3 + 0];
var totalCount = rsBlock[i * 3 + 1];
var dataCount = rsBlock[i * 3 + 2];
for (var j = 0; j < count; j++) {
list.push(new QRRSBlock(totalCount, dataCount));
}
}
return list;
}
QRRSBlock.getRsBlockTable = function(typeNumber, errorCorrectLevel) {
switch (errorCorrectLevel) {
case QRErrorCorrectLevel.L:
return QRRSBlock.RS_BLOCK_TABLE[(typeNumber - 1) * 4 + 0];
case QRErrorCorrectLevel.M:
return QRRSBlock.RS_BLOCK_TABLE[(typeNumber - 1) * 4 + 1];
case QRErrorCorrectLevel.Q:
return QRRSBlock.RS_BLOCK_TABLE[(typeNumber - 1) * 4 + 2];
case QRErrorCorrectLevel.H:
return QRRSBlock.RS_BLOCK_TABLE[(typeNumber - 1) * 4 + 3];
default:
return undefined;
}
}
//---------------------------------------------------------------------
// QRBitBuffer
//---------------------------------------------------------------------
function QRBitBuffer() {
this.buffer = new Array();
this.length = 0;
}
QRBitBuffer.prototype = {
get: function(index) {
var bufIndex = Math.floor(index / 8);
return ((this.buffer[bufIndex] >>> (7 - index % 8)) & 1) == 1;
},
put: function(num, length) {
for (var i = 0; i < length; i++) {
this.putBit(((num >>> (length - i - 1)) & 1) == 1);
}
},
getLengthInBits: function() {
return this.length;
},
putBit: function(bit) {
var bufIndex = Math.floor(this.length / 8);
if (this.buffer.length <= bufIndex) {
this.buffer.push(0);
}
if (bit) {
this.buffer[bufIndex] |= (0x80 >>> (this.length % 8));
}
this.length++;
}
};
//---------------------------------------------------------------------
// Support Chinese
//---------------------------------------------------------------------
function utf16To8(text) {
var result = '';
var c;
for (var i = 0; i < text.length; i++) {
c = text.charCodeAt(i);
if (c >= 0x0001 && c <= 0x007F) {
result += text.charAt(i);
} else if (c > 0x07FF) {
result += String.fromCharCode(0xE0 | c >> 12 & 0x0F);
result += String.fromCharCode(0x80 | c >> 6 & 0x3F);
result += String.fromCharCode(0x80 | c >> 0 & 0x3F);
} else {
result += String.fromCharCode(0xC0 | c >> 6 & 0x1F);
result += String.fromCharCode(0x80 | c >> 0 & 0x3F);
}
}
return result;
}
uQRCode = {
errorCorrectLevel: QRErrorCorrectLevel,
defaults: {
size: 354,
margin: 0,
backgroundColor: '#ffffff',
foregroundColor: '#000000',
fileType: 'png', // 'jpg', 'png'
errorCorrectLevel: QRErrorCorrectLevel.H,
typeNumber: -1
},
make: function(options) {
return new Promise((reslove, reject) => {
var defaultOptions = {
canvasId: options.canvasId,
componentInstance: options.componentInstance,
text: options.text,
size: this.defaults.size,
margin: this.defaults.margin,
backgroundColor: this.defaults.backgroundColor,
foregroundColor: this.defaults.foregroundColor,
fileType: this.defaults.fileType,
errorCorrectLevel: this.defaults.errorCorrectLevel,
typeNumber: this.defaults.typeNumber
};
if (options) {
for (var i in options) {
defaultOptions[i] = options[i];
}
}
options = defaultOptions;
if (!options.canvasId) {
console.error('uQRCode: Please set canvasId!');
return;
}
function createCanvas() {
var qrcode = new QRCode(options.typeNumber, options.errorCorrectLevel);
qrcode.addData(utf16To8(options.text));
qrcode.make();
var ctx = uni.createCanvasContext(options.canvasId, options.componentInstance);
ctx.setFillStyle(options.backgroundColor);
ctx.fillRect(0, 0, options.size, options.size);
var tileW = (options.size - options.margin * 2) / qrcode.getModuleCount();
var tileH = tileW;
for (var row = 0; row < qrcode.getModuleCount(); row++) {
for (var col = 0; col < qrcode.getModuleCount(); col++) {
var style = qrcode.isDark(row, col) ? options.foregroundColor : options.backgroundColor;
ctx.setFillStyle(style);
var x = Math.round(col * tileW) + options.margin;
var y = Math.round(row * tileH) + options.margin;
var w = Math.ceil((col + 1) * tileW) - Math.floor(col * tileW);
var h = Math.ceil((row + 1) * tileW) - Math.floor(row * tileW);
ctx.fillRect(x, y, w, h);
}
}
setTimeout(function() {
ctx.draw(false, (function() {
setTimeout(function() {
uni.canvasToTempFilePath({
canvasId: options.canvasId,
fileType: options.fileType,
width: options.size,
height: options.size,
destWidth: options.size,
destHeight: options.size,
success: function(res) {
let resData; // 将统一为base64格式
let tempFilePath = res.tempFilePath; // H5为base64，其他为相对路径
// #ifdef H5
resData = tempFilePath;
options.success && options.success(resData);
reslove(resData);
// #endif
// #ifdef APP-PLUS
const path = plus.io.convertLocalFileSystemURL(tempFilePath) // 绝对路径
let fileReader = new plus.io.FileReader();
fileReader.readAsDataURL(path);
fileReader.onloadend = res => {
resData = res.target.result;
options.success && options.success(resData);
reslove(resData);
};
// #endif
// #ifdef MP-WEIXIN || MP-QQ || MP-TOUTIAO
uni.getFileSystemManager().readFile({
filePath: tempFilePath,
encoding: 'base64',
success: res => {
options.success && options.success(resData);
reslove(resData);
}
})
// #endif
// #ifndef H5 || APP-PLUS || MP-WEIXIN || MP-QQ || MP-TOUTIAO
if (plus) {
const path = plus.io.convertLocalFileSystemURL(tempFilePath) // 绝对路径
let fileReader = new plus.io.FileReader();
fileReader.readAsDataURL(path);
fileReader.onloadend = res => {
resData = res.target.result;
options.success && options.success(resData);
reslove(resData);
};
} else {
uni.request({
url: tempFilePath,
method: 'GET',
responseType: 'arraybuffer',
success: res => {
options.success && options.success(resData);
reslove(resData);
}
})
}
// #endif
},
fail: function(error) {
options.fail && options.fail(error);
reject(error);
},
complete: function(res) {
options.complete && options.complete(res);
}
}, options.componentInstance);
}, options.text.length + 100);
})());
}, 150);
}
createCanvas();
});
}
}
})()
export default uQRCode
扫一扫
9611
被折叠的 条评论
为什么被折叠?
到【灌水乐园】发言
