This is Chevron Motor Corp, based in the state of New York.
-First they made an experimental 5-cylinder radial engine giving 100 hp.
-But their better known engines are two 7-cylinder radials.
-The A and A-L, models, which are only varying in compression ratio for the use of different gasolines.
"Chevron A"
-It is interesting to observe that the exhaust pipe from the lower cylinder is closer to the carburetor and that it is used for heating against icing.
Engines of CHEVRON
Model: 5 cyl. radial A and AL model
Model: 7 cyl.. radial, 100 HP, model A-L
"Chevron A"
